Seg WI Series Reference Manual

CLPU . 50 N/G, 51 N/G Factor [Protection Para / CLPU]
150%
Only available if:
• CLPU . 50 N/G, 51 N/G Stab. = Factor•
100% . . . 500% P.1
If the operating mode has been set to increase the pickup threshold then this is the factor by which the pickup
threshold of each the Ground (Earth) Overcurrent stage is multiplied during the CLPU stabilization.
CLPU . tO󰈚 [Protection Para / CLPU]
120.0min 0.1min . . . 240.0min P.1
Timer stage, that is started when the breaker position is detected as O󰅯. (The next re-energization after this timer
has expired will trigger the CLPU stabilization.)
CLPU . tStab [Protection Para / CLPU]
5.0s 0.1s . . . 1000.0s P.1
Duration of the CLPU stabilization. This timer stage is started when the CLPU stabilization is triggered.
CLPU . ExBlo [Protection Para / CLPU]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
9.21.3
CLPU: Input States
CLPU . ExBlo-I [Operation / Status Display / CLPU]
Module input state: External blocking
9.21.4
CLPU: Signals (Output States)
CLPU . Active [Operation / Status Display / All Actives]
[Operation / Status Display / CLPU]
Signal: active
CLPU . detected [Operation / Status Display / CLPU]
Signal: The CLPU stabilization has been triggered.
CLPU . stab. [Operation / Status Display / CLPU]
Signal: The CLPU stabilization is active.
