Description
Prot . Pickup Ext. Signal: General Pickup due to an external signal
Prot . DI 1 Signal: Digital Input
Prot . DI 2 Signal: Digital Input
Prot . Pos ON Signal: Circuit Breaker is in ON-Position
Prot . Pos OFF Signal: Circuit Breaker is in OFF-Position
Nom voltage
Nominal voltage of the digital inputs
Selection list referenced by the following parameters:
• ╚═▷ Prot . Nom voltage•
Nom voltage Description
24 VDC 24 VDC
48 VDC ... 60 VDC 48 VDC ... 60 VDC
110 VDC 110 VDC
230 VDC 230 VDC
110 VAC 110 VAC
230 VAC 230 VAC
115 VAC / 230 VAC 115 VAC / 230 VAC (depending on the input)
My Language
Selection list referenced by the following parameters:
• ╚═▷ DiggiMEC . Menu language•
My Language Description
English English
Operation Preference
If set to “Early wake-up”, the DiggiMEC is fully available at smaller primary currents,
but at the cost of more inaccurate WIC1 measurement values. If set to “Precise meas.”,
the DiggiMEC gets fully available only with higher primary currents, but the WIC1
132 WIC1 WIC1-2.0-EN-REF
13 Selection Lists
