Description
Ipeak> . Pickup Signal: Pickup
SOTF . Trip Signal: Trip
SOTF . Alarm Signal: Alarm
SOTF . Pickup Signal: Pickup
ExP[1] . Trip Signal: Trip
ExP[1] . Alarm Alarm
ExP[1] . Pickup Signal: Pickup
ExP[2] . Trip Signal: Trip
ExP[2] . Alarm Alarm
ExP[2] . Pickup Signal: Pickup
TCM . Alarm Signal: Alarm
CBF . Alarm Signal: Alarm
BkrWear . Alarm Signal: Alarm: The maximum number of open commands or the maximum value for the
sum of ruptured currents has been exceeded.
BkrWear . Alm(mx.Sum.Tr) Signal: Alarm: The maximum number of open commands has been exceeded.
BkrWear . Alm(mx.Sum.Itrip) Signal: Alarm: The maximum value for the sum of ruptured currents has been exceeded.
BkrWear . Alm (CB Wear
Lev.)
Signal: Alarm: The maximum wear level of the circuit breaker has been exceeded.
CLPU . detected Signal: The CLPU stabilization has been triggered.
CLPU . stab. Signal: The CLPU stabilization is active.
Life Load . Alarm Signal: Alarm
Sys . New error/warning Signal: A new Self-Supervision message (error or warning) has been issued.
Sys . Prot. Ready Signal: The device has completely booted, all protection functions are running and there
is enough electrical energy for a trip pulse.
Sys . Intern.Volt. not OK Signal: The self-supervision of the device has determined a problem with the internal
voltage level or energy supply. This might impair the overall protection functionality,
including the possibility to output a trip pulse. (If the supply via the connected CTs is
su󰅲cient you might want to check for a potential energy drain through the devices
connected to the output(s).)
Prot . TripCmd Signal: Trip Command
Prot . Trip Signal: General Trip
Prot . Alarm Signal: General Alarm
Prot . Pickup Signal: General Pickup
Prot . Trip IPh Signal: General Trip due to a phase current fault
Prot . Trip IG Signal: General Trip due to a ground current fault
Prot . Trip Ext. Signal: General Trip due to an external signal
Prot . Trip IL1 Signal: General Trip due to a fault in phase L1
Prot . Trip IL2 Signal: General Trip due to a fault in phase L2
Prot . Trip IL3 Signal: General Trip due to a fault in phase L3
Prot . Pickup I Ph Signal: General Pickup due to a phase current fault
Prot . Pickup IG Signal: General Pickup due to a ground current fault
131WIC1WIC1-2.0-EN-REF
13 Selection Lists
