Description
“-”
IH2 . Block. L1 Signal: Inrush blocking of phase L1 of the phase overcurrent protection
IH2 . Block. L2 Signal: Inrush blocking of phase L2 of the phase overcurrent protection
IH2 . Block. L3 Signal: Inrush blocking of phase L3 of the phase overcurrent protection
IH2 . Block. Ph. Signal: Inrush blocking of a phase of the phase overcurrent protection
IH2 . Block. 3-ph Signal: 3-phase Inrush blocking: An inrush has been detected in (at least) one phase, so
that all three phases are blocked.
I> . Trip Signal: Trip
I> . Alarm Signal: Alarm
I> . Pickup Signal: Pickup
I>> . Trip Signal: Trip
I>> . Alarm Signal: Alarm
I>> . Pickup Signal: Pickup
I>>> . Trip Signal: Trip
I>>> . Alarm Signal: Alarm
I>>> . Pickup Signal: Pickup
IG> . Trip Signal: Trip
IG> . Alarm Signal: Alarm
IG> . Pickup Signal: Pickup
IG> . IH2 Blo Signal: Blocking the trip command by an inrush
IG>> . Trip Signal: Trip
IG>> . Alarm Signal: Alarm
IG>> . Pickup Signal: Pickup
IG>> . IH2 Blo Signal: Blocking the trip command by an inrush
I2/I1> . Trip Signal: Trip
I2/I1> . Alarm Signal: Alarm
I2/I1> . Pickup Signal: Pickup
I2/I1> . IH2 Blo Signal: Blocking the trip command by an inrush
I2> . Trip Signal: Trip
I2> . Alarm Signal: Alarm
I2> . Pickup Signal: Pickup
I2> . IH2 Blo Signal: Blocking the trip command by an inrush
ThR . Trip Signal: Trip
ThR . Alarm Signal: Alarm
ThR . Pickup Signal: Pickup
ThR . Pre-Alarm Signal: The set value for the Θ Threshold has been exceeded.
Ipeak> . Trip Signal: Trip
Ipeak> . Alarm Signal: Alarm
130 WIC1 WIC1-2.0-EN-REF
13 Selection Lists
