Seg WI Series - Phase and Ground Current Measuring Inputs

IG> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / IG>]
Only available if:
• IG> . De󰊟nition = Alarm•
Signal: Alarm
IG> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / IG>]
Signal: Pickup
IG> . IH2 Blo [Operation / Status Display / IG>]
Signal: Blocking the trip command by an inrush
77WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.11.4 IG>: Signals (Output States)
