Enabling
Select the criterion for determining a manual CLOSE of the breaker. (After this,
the »SOTF« module gets enabled for a particular settable time.)
Selection list referenced by the following parameters:
• ╚═▷ SOTF . Enabling•
Enabling Description
Breaker Pos. A (manual) CLOSE command is determined based on the breaker position. (Note that
the determination of breaker positions needs to be con󰅰gured separately.)
Close Command A CLOSE command being executed enables the »SOTF« module.
Selection list referenced by the following parameters:
• ╚═▷ SOTF . Trigger•
• ╚═▷ ExP[2] . Condition•
Description
“-”
I> . Pickup Signal: Pickup
I>> . Pickup Signal: Pickup
I>>> . Pickup Signal: Pickup
Ipeak> . Pickup Signal: Pickup
Prot . Pickup Signal: General Pickup
Operating Mode
Operating Mode of the Cold Load Pickup stabilization
Selection list referenced by the following parameters:
• ╚═▷ CLPU . 50/51 Stab.•
• ╚═▷ CLPU . 50 N/G, 51 N/G Stab.•
Operating Mode Description
inactive The Cold Load Pickup stabilization is inactive.
Factor The Cold Load Pickup stabilization (temporarily) increases the pickup threshold of the
(phase and/or ground) overcurrent protection.
Block. The Cold Load Pickup stabilization (temporarily) blocks the (phase and/or ground)
overcurrent protection.
145WIC1WIC1-2.0-EN-REF
13 Selection Lists
