Seg WI Series Reference Manual

CT . CT Type [Field Para / CT]
Relative
Only available if:
• Prot . Settings valid = Software•
Relative . . . Standard
╚═▷ CT Type
P.1
Select the connected CT Type (for the display of primary or relative phase current values).
CT . In,relative [Field Para / CT]
1.000In.min
Only available if:
• CT . CT Type = Relative•
1.000In.min . . . 3.500In.min P.1
Relative primary rated current. (This is the rated current divided by the CT ratio, i.e. a value that has been made
independent of the CT type.)
CT . CT pri [Field Para / CT]
0A
Only available if:
• Prot . Settings valid = Software•
If: CT . CT Type = Relative
• 0A . . . 0A•
• 0A . . . 56.0A•
• 0A . . . 56.0A•
• 0A . . . 112.0A•
•
0A . . . 224.0A
•
• 0A . . . 448.0A•
•
0A . . . 896.0A
•
•
0A . . . 10000.0A
•
• 16.0A . . . 0A•
If: CT . CT Type = WE2 : 16 A ... 56 A
•
16.0A . . . 56.0A
•
• 16.0A . . . 56.0A•
• 16.0A . . . 112.0A•
•
16.0A . . . 224.0A
•
•
16.0A . . . 448.0A
•
•
16.0A . . . 896.0A
•
•
16.0A . . . 10000.0A
•
•
16.0A . . . 0A
•
•
16.0A . . . 56.0A
•
If: CT . CT Type = W2 : 16 A ... 56 A
•
16.0A . . . 56.0A
•
•
16.0A . . . 112.0A
•
•
16.0A . . . 224.0A
•
•
16.0A . . . 448.0A
•
P.1
18 WIC1 WIC1-2.0-EN-REF
4 Field settings
4.1.1 CT: Settings
