Seg WI Series Reference Manual

IG> . IG [Protection Para / IG>]
1.00In If: CT . IG Source = calculated AND IG> . Char = DEFT
• 0.20In . . . 10.00In•
If: CT . IG Source = calculated AND IG> . Char = IEC NINV
• 0.20In . . . 2.50In•
If: CT . IG Source = calculated AND IG> . Char = IEC VINV
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = IEC EINV
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = IEC LINV
• 0.20In . . . 2.50In•
If: CT . IG Source = calculated AND IG> . Char = RINV
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = HV Fuse
• 0.20In . . . 2.50In•
If: CT . IG Source = calculated AND IG> . Char = FR Fuse
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = IEEE MINV
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = IEEE VINV
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = IEEE EINV
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = EF Curve
•
0.20In . . . 2.50In
•
If: CT . IG Source = calculated AND IG> . Char = RXIDG
•
0.20In . . . 2.50In
•
If: CT . IG Source = measured AND IG> . Char = DEFT
•
0.02In . . . 10.00In
•
If: CT . IG Source = measured AND IG> . Char = IEC NINV
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = IEC VINV
•
0.02In . . . 2.50In
•
If: CT . IG Source = measured AND IG> . Char = IEC EINV
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = IEC LINV
•
0.02In . . . 2.50In
•
If: CT . IG Source = measured AND IG> . Char = RINV
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = HV Fuse
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = FR Fuse
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = IEEE MINV
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = IEEE VINV
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = IEEE EINV
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = EF Curve
• 0.02In . . . 2.50In•
If: CT . IG Source = measured AND IG> . Char = RXIDG
• 0.02In . . . 2.50In•
P.1
If the pickup value is exceeded, the protection stage starts to time out to trip.
72 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.11.2 IG>: Settings
