Seg WI Series Reference Manual

IG>> . Char [Protection Para / IG>>]
DEFT DEFT . . . RXIDG
╚═▷ Char
P.1
Characteristic
IG>> . t [Protection Para / IG>>]
0.1s
Only available if:
• IG>> . Char = DEFT•
0.00s . . . 300.00s P.1
Time delay for trip or alarm
IG>> . tChar [Protection Para / IG>>]
0.1
Only available if:
• IG>> . Char = IEC NINV•
• IG>> . Char = IEC VINV•
• IG>> . Char = IEC EINV•
• IG>> . Char = IEC LINV•
•
IG>> . Char = RINV
•
•
IG>> . Char = HV Fuse
•
• IG>> . Char = FR Fuse•
• IG>> . Char = IEEE MINV•
•
IG>> . Char = IEEE VINV
•
• IG>> . Char = IEEE EINV•
•
IG>> . Char = EF Curve
•
• IG>> . Char = RXIDG•
0.05 . . . 10.00 P.1
Time multiplier/tripping characteristic factor. The setting range depends on the selected tripping curve.
80 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.12.2 IG>>: Settings
