Seg WI Series Reference Manual

Ipeak> . Trip IL3 [Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L3
Ipeak> . Alarm IL1 [Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Alarm•
Signal: Alarm due to a fault in phase L1
Ipeak> . Alarm IL2 [Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Alarm•
Signal: Alarm due to a fault in phase L2
Ipeak> . Alarm IL3 [Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Alarm•
Signal: Alarm due to a fault in phase L3
Ipeak> . Pickup IL1 [Operation / Status Display / Ipeak>]
Signal: Pickup in phase L1
Ipeak> . Pickup IL2 [Operation / Status Display / Ipeak>]
Signal: Pickup in phase L2
Ipeak> . Pickup IL3 [Operation / Status Display / Ipeak>]
Signal: Pickup in phase L3
98 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.16.4 Ipeak>: Signals (Output States)
