9. ▷

Only in case of an Inverse-Time characteristic:

Specify the »IG>« Earth (Ground) Overcurrent tripping characteristic factor (see ╚═▷

“Explanation for All Characteristics (IG>, IG>>)” for details):

• [Protection Para / IG>] »IG> . tChar«•

10. ▷

If Inrush Blocking has been activated (see ╚═▷ “4.4 IH2 - Inrush Blocking”), select

whether this Earth (Ground) Overcurrent stage shall be blocked in case of an inrush

current:

• [Protection Para / IG>] »IH2 Blo« =•

Options:

◦ “Inactive” (no Inrush blocking of the ground overcurrent protection),◦

◦ “Active” (the Inrush Blocking module also blocks the ground overcurrent◦

protection).

152 WIC1 WIC1-1.0-EN-MAN

4 Protective Elements

4.5.2.1 Earth (Ground) Overcurrent Protection – Settings via DiggiMEC or via Smart view
