9.1.8.3 Relay Ouput (WIC1‑4)
With the device variant WIC1‑4, it is possible via setting [Device Para / WIC1 / Output] »Prot .
Out. Mode« = “Syst. O.K. & Ext.Suppl.” to set the output “Out+/−” up for connecting an
external output relay.
This output relay must fulll the following conditions:
Nominal voltage of the coil: 24 VDC, max. 36 VDC
No internal overvoltage protection allowed
Input current: max. 10 mA
Wiring length: max. 5 m
Example of a usable output relay: Phoenix Relay Module – RIF-0-RSC-24DC/21 – 2903374
9.1.9
Remote (External) Trip Input / Digital Input (WIC1‑1, WIC1‑2,
WIC1‑3)
A device of type WIC11, WIC12, WIC13 can feature a Digital Input (depending on the
order option).
To the terminals X4‑2, X4‑3, X4‑4 (for the connection of 230 VAC, 115 VAC, COM, resp., see
╚═▷ “3.5 Digital Input (only WIC1‑1… / WIC1‑2… / WIC1‑3…)”) of the terminal block X4 the
relevant signaling AC voltage for the input is connected. This input is electrically isolated.
CAUTION!
It is not allowed to connect any continuous voltage to the 115 VAC or 230 VAC input!
Any continuous voltage can destroy the internal signal transformer.
Input voltage range:
•
If operated up to max. 2000 m (above sea-
•
level):
230 VAC ± 15%
• If operated above 2000 m (to max.•
3000 m above sea-level):
230 VAC +13% / −15%
• Alternatively, if operated up to max.•
3000 m (above sea-level):
115 VAC ± 15%
Terminals: Screw-type terminal
209WIC1WIC1-1.0-EN-MAN
9 Technical Data
9.1.8.3 Relay Ouput (WIC1‑4)
