11.2.2.1
DEFT –
Denite
Time-Overcurrent (IG>, IG>>)
100
10
1
0.1
0.01
t / s
IG / IGnom
t
IG>
DEFT
wiEDOC_Z00
1
10
T
rip delay for IG > I
G>
, settable via [Pr
otection P
ara / IG>]
»t«
.
The reset delay for IG < I
G>
always equals 0 (”instantaneous”).
291
WIC1
WIC1-1.0-EN-MAN
11 Appendix
11.2.2.1 DEFT –
Denite
T
ime-
Overcur
rent (IG>, IG>>)
290
292
