9 Technical Data
9.1 Technical Data – WIC1
NOTICE!
Use an Ethernet cable CAT 3 (or better) with shielding for the connection between WIC1
and DiggiMEC. Crossover cables must not be used!
9.1.1 Climatic and Environmental Data
Storage Temperature: −40°C to +85°C (−40°F to 185°F)
Operating Temperature:
• WIC1‑1, WIC1‑2, WIC1‑3: −40°C to +80°C•
(−40°F to 176°F)
• WIC1‑4: −40°C to +60°C (−40°F to 140°F)•
Permissible Humidity at Ann. Average: ≤ 75% rel. (on 56 days up to 95% rel.)
Permissible Installation Altitude: ≤ 2000 m (6561.67 ft) above sea level
up to 3000 m (above sea-level) is permissible
if the smaller tolerance in ╚═▷ “9.1.9 Remote
(External) Trip Input / Digital Input (WIC1‑1,
WIC1‑2, WIC1‑3)” is fullled
Vibration and continuous vibration test: 1 / 2 gn
DIN EN 60255-21-1 [05/96]
Class 2
Shock and continuous shock test: 10 / 20 gn
DIN EN 60255-21-2 [05/96]
Class 2
Earthquake test: 2 gn
DIN EN 60255-21-3 [05/96]
Class 2
9.1.2
Housing
Housing (Height / Width / Depth): 170 mm (6.693 in.) / 125 mm (4.921 in.) /
39.8 mm (1.567 in.)
204 WIC1 WIC1-1.0-EN-MAN
9 Technical Data
9.1 Technical Data – WIC1
