5.3 How to Read Out the Fault Recorder
In order to read out a fault record there are two options available:
• Option 1: A Fault has popped up on the DiggiMEC display (because a trip or pickup•
has occurred).
• Option 2: Call up the Fault Recorder menu manually.•
Option 1 (in case a fault record pops up on the DiggiMEC display (overlay):
• Analyze the fault record by using keys “▲” and “▼”.•
•
Or close the Pop-up by using the »↵« key.
•
Option 2:
• Enter the menu branch [Operation / Recorders / Fault rec], using either the DiggiMEC•
panel or Smart view.
•
Select a fault record.
•
How to Navigate Within the Fault Recorder via DiggiMEC
Navigation within the Fault Recorder Key
Back to overview. ◀
Next (upper) item within this fault record. ▲
Next (lower) item within this fault record. ▼
182 WIC1 WIC1-1.0-EN-MAN
5 Fault Recorder
5.3 How to Read Out the Fault Recorder
