Seg WIC1-3 User Manual

NOTICE!
The „nominal current“ (rated current) In is for all Earth (Ground) Overcurrent stages
dependent on whether the ground (earth) current is measured or calculated. This is
especially true of all settings parameters that are de󰊟ned in units of In.
• Measured ground (earth) current, [Field Para / General Settings] »CT . IG Source« =•
“measured”:
In is the rated current of the ground (earth) CT, and the WIC1 currently supports 1 A
ground (earth) CTs.
•
Calculated ground (earth) current, [Field Para / General Settings] »CT . IG Source« =
•
“calculated”:
In is the rated current of the phase CTs, and this corresponds to the setting [Field
Para / CT] »CT . In,relative«. (See also ╚═▷ “11.1.3 Setting of the Rated CT current
In” and ╚═▷ “4.2 Field Parameters”.)
Pickup
»IG> . IG«
(as a multiple of In)
HEX 7 DIP 4-1 DIP 4-2 DIP 4-3 DIP 4-4
0.2 0 OFF OFF OFF OFF
0.3 1 ON OFF OFF OFF
0.4 2 OFF ON OFF OFF
0.5 3 ON ON OFF OFF
0.6 4 OFF OFF ON OFF
0.7 5 ON OFF ON OFF
0.8 6 OFF ON ON OFF
0.9 7 ON ON ON OFF
1.0 8 OFF OFF OFF ON
1.2 9 ON OFF OFF ON
1.4 A OFF ON OFF ON
1.6 B ON ON OFF ON
1.8 C OFF OFF ON ON
2.0 D ON OFF ON ON
2.5 E OFF ON ON ON
This setting deactivates the
protection stage.
F ON ON ON ON
266 WIC1 WIC1-1.0-EN-MAN
11 Appendix
11.1.5 Earth (Ground) Overcurrent Protection – Settings via DIP Switches (WIC1‑2) or via HEX Switches (WIC1‑3)
