119
PARTS LIST
19
5 ASSY MONITOR CABI (RD-1200UK) (D-2/2)
ITEM NO PART NUMBER DESCRIPTION QTY
***1 PD-1250XUK ASSY SUB MONITOR CABI 1
***3 PD-1290UK ASSY 42" LCD MONITOR 1
***4 130-5284 SPEAKER 8OHM F01612HO NJS 2
***5 PD-1300XUK ASSY MONITOR MASK 1
***7 RD-2000ZUK ASSY CONTROL PANEL 1
***10 RD-1203UK SIDE PANEL HOLDER 2
***12 GST-1340UK ASSY 12V DC FAN 1
***14 RD-1207UK MONITOR CABI SPACER L 1
***15 RD-1208UK MONITOR CABI SPACER R 1
***17 RD-1214UK CHUTE TOWER HOLDER 4
***19 RD-1209-AUK SIDE PANEL L BLANK 1
***20 RD-1210-AUK SIDE PANEL R BLANK 1
***21 PD-1209-BUK STICKER SIDE PANEL L 1
***22 RD-1210-BUK STICKER SIDE PANEL R 1
***101 253-5460-01 AIR VENT BLACK 3
***102 FR-838-001UK MOTOR CONT ISO HAPP 50-2000-03 1
***103 400-050-024-01 PSU 24VDC 50W MW LPS-50-24 1
***104 400-075-024-01 PSU 24VDC 75W MW LPS-75-24 1
***105 838-0005UK I/O BOARD SAE 1
***106 838-14988 2 CH 30W AUDIO AMP ST 1
***107 400-065-0512-01 PSU 5V-12V DC 65W MW RPD-65C 1
***108 OS1011 PCB FEET RICHCO LCBS-L-5-01 12
***112 838-14551-02UK AC DISTRIBUTION BOARD 1
***113 CFB-4003-01UK EARTH TERMINAL PLATE 1
***201 000-P00416-WB M4X16 MSCR PAN W/FS BLK 6
***202 050-F00600 M6 NUT FLG SER PAS 8
***203 012-P03506-F N6X1/4" S/TAP FLG PAS 12
***204 068-652016 M6 WSHR 20OD FLT PAS 8
***205 012-P03512-F N6X1/2" S/TAP FLG PAS 10
***206 068-441616-0B M4 WSHR 16OD FLT BLK 24
***207 029-B00870-OB M8X70 SKT BH BLK 6
***208 060-F00800-0B M8 WSHR FORM A FLT BLK 6
***209 068-852216-0B M8 WSHR 22OD FLT BLK 2
***210 000-T00412-0B M4X12 MSCR TH BLK 18
***211 012-F03512 N6X1/2" S/TAP CSK PAS 12
***212 000-T00416-0B M4X16 MSCR TH BLK 12
***213 050-F00400 M4 NUT FLG SER PAS 3
***214 060-F00400 M4 WSHR FORM A FLT PAS 6
***216 000-P00420-WB M4X20 MSCR PAN W/FS BLK 4
***217 000-P00410-W M4X10 MSCR PAN W/FS PAS 4
***218 012-P00325 N4X1" S/TAP PAN PAS 12
***301 RD-60001UK WH AC TO DIST 1
***303 RD-60006UK WH DC I/O 1
***304 RD-60007UK WH DC AMP 1
***301 RD-60004UK WH LED FRONT CABI 1
***302 RD-60011UK WH SPEAKER B 1
***303 RD-60017UK WH CNTL PNL EXTN 1
***304 RD-60029UK WH AC BB LCD 1
***306 RD-60038UK WH LED FLEXI LINK 1
***307 RD-60020UK WH SPEAKER D 2
***308 RD-60018UK WH RACE LEADER 1
