There is an interference prevention wire on the lower level inside the left side front door.
6-11 FIG. 09
4
Disconnect the connector from CN1 and remove
the interference prevention wire (RMB-60047).
6-11 FIG. 10
5
If several of the same type of game machines are to be installed beside each other, they should be lined
up alternating between ones with the interference prevention wire connected and ones that with the wire
removed. Be sure to keep the removed interference prevention wire.
INTERFERENCE PREVENTION WIRE
Disconnect the connector.
XH3P
