Installation Instructions TM50/TM80 - MO911/1V0
Page 7
The front xing angle can be mounted either at the lintel or at the
ceiling�
1. Meassure the middle of your garage door and make a mark on
the lintel and the top of your door (1)�
2. Fix the front xing angle in the middle either at the lintel or at
the ceiling (lintel recommended) (1)�
3. Attach the C-rail to the front xing angle (2)� Put a carton piece
under the motor head unit to avoid damages�
4. To t the motor head to the ceiling it is recommend to use a
ladder (4)� When the operator is laying on the ladder you can
open the garage-door� Adjust the C-rail according to the mark you
made in the middle of the garage-door�
Fit the operator to the ceiling when you have made sure the C-rail
is running straight to the front� Use the supplied bracket to x the
C-rail to the ceiling (3)�
5. Now t the door arm to the garage door (5)� Take care that the
angle between the operator and the door arm does not exceed a
max� of 45° (it may be lower)�
6. The limit-blocks must be tightened and the programming
must be started before running the operator (page 8)!
The garage doors‘ locks must be removed before running
the operators - otherwise damages on the garage door or
operator might occure!
For additional security our locking set can be obtained as an
optional extra�
Installation
Installation
