107
K600000000SE 030804 011018
13.8 NEW PIPING: UNI 7129-1: 2015 STANDARD
(when the instrument version so provides)
CONTEXT KEY FUNCTION
Enters the modification mode for the selected parameter.
Goes to the next phase of the tightness test.
Performs pressure zeroing.
Interrupts the current phase.
Repeats the tightness test.
Saves, in the memory selected in the "Select Memory" menu, the data
acquired.
The tightness test has been saved.
Starts printing the paper print-out.
KEY FUNCTION
Activate the context keys shown on the display.
Selects line; the selected line is displayed in red.
In edit mode, it sets the desired value.
Activates the context key located in the left side of the display.
Returns to the previous screen.
When in modify mode cancels the modification just made.
O
15/01/14
10:00
UNI 7129
Configuration
Stabilization
min
15
Print
auto
Volume setup
manual
Volume
dm
3
18.0
Measure volume
Calculate volume
Duration of the stabilization phase that can be set between 15 and 240 minutes
Printing mode, that can be set as manual or automatic.
Volume input mode can be set as 'manual' or 'default'.
System volume, which can be set if known.
Measures the volume of the system.
Calculates the volume on the basis of the characteristics of the piping.
