5.0 DESCRIPTION OF COMPONENTS
LEGEND:
A
B
C
P
O
Q
Q Q
E
D
G
L M
I
F
N
H
A
keypad
Adhesive polyester keypad with preformed keys featuring main control functions.
KEYS FUNCTION
Activates the context
keys shown on the
display
Access to the Memory
menu
Access to the Printing
menu
Access to the
Configuration menu
Performs the analysis of
the combustion
Access to the
Measurements menu
KEYS FUNCTION
Turns the device On /
Off
Exits the current screen
Select and/or Modify
Confirm settings
+ Backlight turn-off.
