8.5.10 Draft measurement pressure gauge compliant with UNI 10845 standard.
This device has been designed to extend the functions of the combustion analyzer to the draft measurement in
compliance with the UNI 10845 standard. It enables the combustion analyzer to measure the draft and generally
the pressure with an higher accuracy and resolution than the internal sensor of the instrument.
Connection
As shown on the section 8.5 the probe shall be connected to the instrument as follows:
 The draft gauge is provided with a female connector (ø 9mm) of the same type of the one for the pressure
inputs on the combustion analyzer. Thanks to this connector the draft gauge can be connected directly to the
shorter male connector (ø 9mm) of the flue gas sampling probe supplied.
The 8-pole MiniDin connector shall be connected to the serial port of the analyzer ( chapter 5).
8.5.11 Pressure Test Kit
Two types of pressure measurement kit are available:
1st Kit includes two 1mt hoses and two ø 9mm fittings; to be used for the differential pressure measurement.
2nd Kit includes one 1mt hose and one ø9mm fitting for pressure measurement.
Connection
As shown on section 8.5 the kits shall be connected to the instrument as follows:
1st hose connector shall be connected to the P+ connector, while the other hose connector shall be connected
to the analyzer P- connector.
2nd The hose connector shall be connected to the analyzer P+ or P- connector.
8.5.12 Burner pressure verification probe
This probe must be used to measure the burner pressure of the gas-powered boiler so it can be regulated in real
time. It is made of a silicone tube, 8x4mm and 1 metre long, complete with connector for connecting to the
analyser.
Connection
As shown on section 8.5 the kits shall be connected to the instrument as follows:
The hose connector shall be connected to the analyser P+ connector.
8.5.13 Connection to PC
By using the USB cable supplied or via Bluetooth connection (optional) it is possible to connect the device to a
personal computer after installing the dedicated software supplied.
Functions:
 View the details of the analyser.
 See and/or export (in csv format, importable into excel, and/or pdf) or delete the stored analyses.
 Configure the device.
8.5.14 Connection to battery charger
Supplied with the device there is a power plug with output 5V , 2A to charge the internal batteries. In section 5
you can see the socket for the connection of the battery charger to the device. Once it has started charging, the
display turns on and the state of charge of the battery is displayed.
