16.5 Replacing the particulate filter
If the filter is wet or has any cracks or significant build-up of dust/ash/particulates on it, especially on the inner
surface (see adjacent example), it has to be replaced immediately. In this way gas flow is not obstructed.
Blackened particulate filter
16.4 Maintaining the water trap / filter unit
To remove the water trap, just rotate the cover and unhook the filter holder body; remove the internal cup and
then replace the filter (see figure on the side).
Clean all the filter parts using water only, dry the components and reassemble the filter.
