162
K600000000SE 030804 011018
15.5 Expandability to 6 sensors
The CHEMIST 600 Emissions Analyzer can be expanded up to 6 cells.
THE INSTRUMENT AUTOMATICALLY DETECTS WHEN AN ADDITIONAL SENSOR IS
INSTALLED OR HAS BEEN REMOVED. THE SCREEN 'SENSORS CONFIGURATION'
ALLOWS TO ACCEPT THE NEW PROPOSED CONFIGURATION OR TO IGNORE THE
CHANGE DETECTED.
IN THIS SCREEN ARE SHOWN, FOR EACH POSITION, THE FOLLOWING MESSAGES:
EXAMPLE OF AN 'NO' SENSOR IN POSITION 3 REPLACED WITH AN 'NO2' SENSOR:
NO→NO2 A SENSOR DIFFERENT FROM THE PREVIOUS ONE HAS BEEN DETECTED.
EXAMPLE OF A NEW SENSOR INSTALLED IN POSITION 4 (PREVIOUSLY NOT PRESENT):
SO2→□ A NEW SENSOR HAS BEEN DETECTED.
The upgrading of the number of sensors can be easily done by the user by performing the following directions:
- The expandable instruments are arranged in a way to accept up to a maximum of 6 cells.
- Identify, with the help of paragraph 15.2 'Sensor types and relevant positioning' the sensor(s) which must be
added to the existing configuration (Seitron delivers all FLEX-series sensors already pre-calibrated and ready
to use).
- To install the new sensors follow all the steps described in the paragraph 'MAINTENANCE' under 'gas sensors
replacement'.
