26
K600000000SE 030804 011018
Hose: Material: EPDM
Length: 3 m
Filter: AISI 316L sintered stainless steel, washable with ultrasonic bath or with
solvents and steel brush.
Temperature sensor: Type K thermocouple (Ni-NiCr) - IEC584 - Class 1
Pneumatic connectors: Male - 8.9 mm diameter
Male - 8.0 mm diameter
Temperature sensor connector: TcK mignon size
Operating temperature: max. 800°C
8.5.6 Ambient CO probe
This special probe allows the ambient CO measurement before accessing the boiler room and just then, to
measure the CO in the environment while the combustion analysis is performed (as, for example, compelled by
the Spanish standard ES.02173.ES, Gas Natural Fenosa), prior entering the data “CO amb. ext.” in the
parameter “configuration measurement list”.
The value of the ambient CO can be also printed along with the combustion analysis, if previously selected in the
parameter “Print measurement list”.
For further details refer to the probe instruction manual.
8.5.7 Combustion air temperature sensor
This probe is used to measure the temperature of the incoming combustion air.
Use: to be used when the sampling site of the combustion air is located in a different area than the boiler room or
the heating plant; when the combustion air sampling site is located in a different place than the boiler room, the
temperature of the combustion air can be very different compared with the temperature of the air in the boiler
room, generating a less accurate efficiency calculation.
Technical features:
Tip: Material: AISI 304 stainless steel
Diameter: 6 mm
Length: 200 mm rigid tip
Adapter for thermowells: Material: AISI 303 stainless steel
External diameter: 7,5 .. 17 mm
Temperature sensor: Sensing element: Type K thermocouple (Ni-NiCr) - IEC584 - Class 1
Cable length: 2 m
Connector: TcK mignon size
Measurement range: -20.0°C .. +200.0°C
Connection
As shown in section 8.5 the probe must be connected to the instrument as follows:
The polarized male connector of the thermocouple must be connected to the T2 plug. The improper insertion
of the same is not possible thanks to the different length of the tips.
8.5.8 Tc-K temperature measurement probe
Using the same input as for the Tc-K thermocouple ‘T1’ (i.e. the one used for gas temperature), it is possible to
measure the supply and return water temperature. If this temperature is taken on the pipe itself, it is suggested to
use contact probes with diameter matching as close as possible the pipe diameter.
Connection
As shown in section 8.5 the probe must be connected to the device as follows:
The polarized male connector of the thermocouple must be connected to the ’T1’ plug. The improper insertion
of the same is not possible thanks to the different lengths of the tips.
8.5.9 Ionization current measurement probe
This special probe has been developed to extend the functions of the analyzer to check the quality of the
combustion flame.
This probe allows the combustion analyzer to measure the current that is created within the combustion chamber
between the chamber metal body and the measurement electrode.
Connection
As shown in section 8.5 the probe must be connected to the device as follows:
The 8-poles mini-DIN type connector must be connected to the serial port on the analyzer ( chapter 5).
E
