Example of the exported csv file and imported in an excel file:
Chemist 600
Serial number 1100
Date 15/12/2017
Time 12:00
Fuel Natural gas
Altitud. 0.000000 m
Air humidity 50 %
O2 15.7 %
CO 23 ppm
CO2 2.9 %
T smoke 100.6 °C
T air 27.0 °C
ηs 90.0 %
NO 0.000 mV
CO-SEN 258.270 mV
O2 1.131.867 mV
I sen 0.000 uA
I sen 0.000 uA
I sen 100.346 uA
T az 22.5 °C
ΔT 73.6 °C
Qs 10.0 %
λ,n 4.01
Air excess 4.01
ηc 0.0 %
ηt 90.0 %
Qs (PCS) 10.0 %
Qt (PCS) 10.0 %
ηs (PCS) 90.0 %
ηc (PCS) 0.0 %
ηt (PCS) 90.0 %
NO 0 ppm
NOx 0 ppm
CO (0.0%) 0 ppm
NO (0.0%) 0 ppm
NOx (0.0%) 0 ppm
Draught 4.5 Pa
Insert an email address if
different from the default
one.
Select one of the two
modes of data sharing.
Select the file format to
share.
Select the application to
use for sending.
