Schweitzer Engineering Laboratories, Inc. SEL-487E-3, -4 Data Sheet
25
➤
Ethernet card options
➢ Ethernet card with combinations of 10/
100BASE-T and 100BASE-FX media
connections on each of two ports.
➤ Ethernet communications protocols
➢ Standard (FTP, Telnet, DNP3, PRP)
➢ Standard plus IEC 61850
Contact the SEL factory or your local Technical Service
Center for particular part number and ordering informa-
tion (see Technical Support on page 33). You can also
view the latest part number and ordering information on
the SEL website at selinc.com.
Specifications
Note: TiDL (EtherCAT) technology is no longer offered in the SEL-487E-3, -4.
TiDL (T-Protocol) is available in the SEL-487E-5. If the relay is using a
TiDL (EtherCAT) system, such as TiDL, the operating times will be delayed
by 1.5 ms. Use caution when setting the relay coordination times to account
for this added delay. Element operate times will also have this small added
delay.
Compliance
Designed and manufactured under an ISO 9001 certified quality
management system
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference in which case the
user will be required to correct the interference at his own expense.
UL Listed to U.S. and Canadian safety standards
(File E212775; NRGU, NRGU7)
CE Mark
General
AC Analog Inputs
Sampling Rate: 8 kHz
AC Current Inputs (Secondary Circuits)
Note: Current transformers are Measurement Category II.
Input Current
5 A Nominal: S, T, U, W, X, and Y terminals
1 A Nominal: S. T, U, W, X, and Y terminals
1 A/5 A Nominal: Y terminal only (REF)
Current Rating (With DC Offset at X/R = 10, 1.5 cycles)
5 A Nominal: 91.0 A
1 A Nominal: 18.2 A
Continuous Thermal Rating
5 A Nominal: 15 A
20 A (+55°C)
1 A Nominal: 3 A
4 A (+55°C)
Saturation Current (Linear) Rating
5 A Nominal: 100 A
1 A Nominal: 20 A
One-Second Thermal Rating
5 A Nominal: 500 A
1 A Nominal: 100 A
One-Cycle Thermal Rating
5 A Nominal: 1250 A-peak
1 A Nominal: 250 A-peak
Burden Rating
5 A Nominal: 0.5 VA at 5 A
1 A Nominal: 0.1 VA at 1 A
A/D Current Limit
Note: Signal clipping may occur beyond this limit.
5 A Nominal: 247.5 A
1 A Nominal: 49.5 A
AC Voltage Inputs
Three-phase, four-wire (wye) connections are supported.
Rated Voltage Range: 55–250 V
LN
Operational Voltage Range: 0–300 V
LN
Ten-Second Thermal
Rating: 600 Vac
Burden: 0.1 VA @ 125 V
LEA Voltage Inputs
Rated Voltage Range: 4 V
L-N
Operational Voltage Range: 0–8 V
L-N
Ten-Second Thermal
Rating: 300 Vac
Input Impedance: 1 M
Frequency and Rotation
Rotation: ABC
ACB
Nominal Frequency Rating: 50 ±5 Hz
60 ±5 Hz
Frequency Tracking
(Requires PTs):
Tracks between 40.0–65.0 Hz
Below 40.0 Hz = 40.0 Hz
Above 65.0 Hz = 65.0 Hz
Maximum Slew Rate: 15 Hz/s
Power Supply
24—48 Vdc
Rated Voltage: 24–48 Vdc
Operational Voltage Range: 18–60 Vdc
Vdc Input Ripple: 15% per IEC 60255-26:2013
Interruption: 20 ms at 24 Vdc, 100 ms at 48 Vdc
per IEC 60255-26:2013
Burden: <35 W
48—125 Vdc or 110—120 Vac
Rated Voltage: 48–125 Vdc, 110–120 Vac
Operational Voltage Range: 38–140 Vdc
85–140 Vac
