Selec ATSEL FD300

Dead time of
FWD / REV
0.0~50.0 s
• It mainly applied to the setting of transient time for zero output
frequency during the transient process between forward and reverse.
Please refer to the following graph:
P2-09
Default:
0.2s
Output frequency
Output voltage
Braking before starting
Stop and Braking
Time
Run signal
Time
Output frequency
FWD
Dead time
REW
Run time
P2-05
Default: 1
Stop Mode
0 : Regular stopping
1 : Stop by decelerating
2 : Decelerating - DC braking - Stopping
It's mainly applied to the setting of stop mode for converter.
0: Regular stopping - the output of converter will be blocked immediately once stop
instruction comes into effect.
1: Stopping by decelerating -- output frequency will be decreased slowly according to
the preset deceleration time once stop instruction comes into effect; when it comes to
zero, converter will be shut down.
2: Decelerating - DC braking - Stopping: output frequency will be reduced down to
start frequency(P2-06) according to the preset deceleration time once stop instruction
comes into effect; since then, DC braking will be enabled; after braking time(P2-08) is
over, converter will be shut down.
P2-06
Default:
2.0Hz
0.0 ~ 10.0Hz
Start frequency
of
DC braking
• If parameter P2-05 equals two, it will be stopped through DC braking when
converter reaches up to the corresponding frequency.
P2-07
Default:
50.0%
0 ~ 150.0%
Braking current before starting
P2-08
Braking current before starting
0 ~ 50.0s
Default:
0.0s
• Braking current for stopping means the amperage of direct current for braking;
the higher the amperage is, the stronger the braking force will be.
Braking time for stopping means the time for increasing enough amperage of
direct current to stop converter; when the value comes to zero, it means that
there is no DC braking during the process.
39
38
P8: Auxiliary Functions
Parameter
Name
Setting Range
Default
Prope-
rty
Modbus
Address
○
P8-00
Jog running
frequency
0.00Hz〜Maximum frequency
2.00Hz
P8-01
Jog
acceleration
time
0.0s〜6500.0s 20.0s
P8-02
Jog
deceleration
time
0.0s〜6500.0s 20.0s
P8-03
Acceleration
time 1
0.0s〜6500.0s
P8-04
Deceleration
time 1
0.0s〜6500.0s
P8-05
Acceleration
time 2
0.0s〜6500.0s
P8-06
Deceleration
time 2
0.0s〜6500.0s
P8-07
Acceleration
time 3
0.0s〜6500.0s
P8-08
Deceleration
time 3
0.0s〜6500.0s
P8-09
Jump
frequency 1
0.00Hz〜Maximum frequency
0.00Hz
P8-10
Jump
frequency 2
0.00Hz〜Maximum frequency
0.00Hz
P8-11
Jump frequency
amplitude
0.00Hz〜Maximum frequency
0.00Hz
P8-12
Forward/
Reverse
rotation dead-
zone time
0.0s〜3000.0s 0.0s
P8-13
Reverse
control enable
0 : Allow
1 : Prohibit
0
P8-14
Running mode
when set fre-
quency lower
than frequency
lower limit
0
P8-15
Droop control
0.00Hz〜10.00Hz 0.00Hz
P8-16
Set the
cumulative
power-on
arrival time
0h〜65000h 0h
P8-17
Set cumulative
run arrival time
0h〜65000h 0h
P8-18
Startup
protection
0 : no protection
1 : protection
0
P8-19
Frequency
detection
value FDT1
0.00Hz〜Maximum frequency
50.00Hz
P8-20
Frequency
detection
hysteresis
value (FDT1)
0.0%〜100.0%(FDT1)
5.0%
P8-21
Frequency
arrival
detection width
0.0%~100.0%
(Maximum frequency)
0.0%
P8-22
Jump
frequency
during acc./dec.
0 : Invalid
1 : Valid
0
P8-25
Frequency
switchover
point between
acceleration
time 1 & acc-
eleration time 2
0.00Hz〜Maximum frequency
0.00Hz
P8-26
Frequency
switchover
point between
deceleration
time 1 & dec-
eleration time 2
0.00Hz〜Maximum frequency
0.00Hz
P8-27
Terminal JOG
priority
0:Invalid
1:Valid
0
P8-28
Frequency
detection
value FDT2
0.00Hz〜Maximum frequency
50.00Hz
P8-29
Frequency
detection
hysteresis
value (FDT2)
0.0%〜100.0%（FDT2）
5.0%
P8-30
Arbitrary arrival
frequency
detection
value 1
0.00Hz〜Maximum frequency
50.00Hz
Fun-
ction
Code
○
Model
dependent
Model
dependent
○
○
○
Model
dependent
Model
dependent
Model
dependent
Model
dependent
○
○
○
○
○
○
○
○
○
○
0 : Run at the following
frequency limit
1 : stop
2 : Zero speed operation
○
Fun-
ction
Code
Parameter
Name
Setting range
Default
Prope-
rty
Modbus
Address
○
○
○
○
○
○
○
○
○
○
○
○
○
User Manual
Chapter 5
User Manual
Chapter 5
63489
63490
63491
63492
63493
63494
63495
63496
63497
63498
63499
63500
63501
63502
63503
63504
63505
63506
63507
63508
63509
63510
63513
63514
63515
63516
63517
63518
63519
