Selec ATSEL FD300

37
36
P7-02
1
P7-03
LED display
running
parameters 1
1F
P7-04
LED display
running
parameter 2
0
P7-05
LED stop
display
parameters
33
P7-06
Load speed
display
coefficient
0.0001〜6.5000 1.0000
P7-07
Heatsink
temperature
of AC drive
IGBT
0.0℃〜100.0℃
-
×
P7-08
Product ID
- -
×
P7-09
Accumulative
running time
0h〜65535h
-
×
P7-10
P7-11
Software
version number
-
P7-12
Number of
decimal places
for load speed
display
21
P7-13
Accumulative
power-on time
0〜65535h
-
×
0: STOP/RESET key enabled
only in operation panel control
1: STOP/RESET key enabled
in any operation mode
Function
Code
Parameter
Name
Setting Range
Default
Prope-
rty
Modbus
Address
○
○
STOP/
RESET key
function
0000~FFFF
Bit0 : Running frequency 1(Hz)
Bit1 : Set frequency (Hz)
Bit2 : Bus voltage (V)
Bit3 : Output voltage (V)
Bit4 : Output current (A)
Bit5 : Output power (kW)
Bit6 : Output torque (%)
Bit7 : Input status
Bit8 : Output Status
Bit9 : AI1 Voltage (V)
Bit10 : AI2 voltage (V)
Bit11 : AI3 voltage (V)
Bit12 : Count value
Bit13 : Length value
Bit14 : Load speed display
Bit15 : PID setting
○
0000~FFFF
Bit0 : PID feedback
Bit1 : PLC stage
Bit2 : Pulse input frequency
(kHz)
Bit3 : Running frequency 2 (Hz)
Bit4 : Remaining running time
Bit5 : AI1 pre-correction
voltage (V)
Bit6 : AI2 pre-correction
voltage (V)
Bit7 : AI3 pre-correction
voltage (V)
Bit8 : Linear speed
Bit9 : Current power-on time
(Hour)
Fun-
ction
Code
Parameter
Name
Setting range
Default
Prope-
rty
Modbus
Address
○
0000~FFFF
Bit00 : Set frequency (Hz)
Bit01 : Bus voltage (V)
Bit02 : X input status
Bit03 : Output status
Bit04 : AI1 voltage (V)
Bit05 : AI2 voltage (V)
Bit06 : AI3 voltage (V)
Bit07 : count value
Bit08 : Length value
Bit09 : PLC stage
Bit10 : Load stage
Bit11 : PID setting
Bit12 : PULSE setting frequency
(kHz)
○
Product ID
- -
×
-
×
○
0 : 0 decimal place
1 : 1 decimal place
2 : 2 decimal places
3 : 3 decimal places
P7-14
Accumulative
power
consumption
0〜65535 degree
-
×
User Manual
Chapter 5
User Manual
Chapter 5
P7: K eypad and display
P7-01
JOG/REV
key
function
selection
0
●
0 : JOG/REV key is invalid
1 : Switchover between
operation panel control and
remote command control
(terminal or communication)
2 : Switchover between forward
rotation and reverse rotation
3 : Forward JOG
4: Reverse JOG
Bit10 : Current running time (Min)
Bit11 : PULSE setting frequency (Hz)
Bit12 : Communication setting value
Bit13 : Encoder feedback speed\
(Hz)
Bit14 : Main frequency X Display
(Hz)
Bit15 : Auxiliary frequency Y
display (Hz)
63234
63235
63236
63237
63238
63239
63240
63241
63242
63243
63244
63245
63246
63247
