Selec ATSEL FD300

35
34
P5-21
Y3 Delay
time
(expansion)
0.0s〜3600.0s 0.0s
P5-22
Output
terminal
valid mode
selection
00000
Function
Code
Parameter
Name
Setting Range
Default
Prope-
rty
Modbus
Address
○
○
Ones place:Y2
Tens place: Relay
Hundreds place : Relay 2
Thousands place : Y1
Ten thousand: Y3
0: The output terminal is
connected to COM and the
disconnection is invalid.
1: The output terminal is not
connected to COM, and the
disconnection is valid.
P6: Start and stop control mode
Function
Code
Parameter
Name
Setting Range
Default
Prope-
rty
Modbus
Address
○
P6-00
Start mode
0
P6-01 0
●
P6-02
Rotational
speed
tracking
speed
1〜100 20
P6-03
Startup
frequency
0.00Hz〜10.00Hz 0.00Hz
P6-04
Startup
frequency
holding time
0.0s〜100.0s 0.0s
●
P6-05
Startup DC
braking
current/Pre-
excited
current
0%〜100% 0%
P6-06
Startup DC
braking
time/Pre-
excited time
0.0s〜100.0s 0.0s
P6-07
Acceleration/
Deceleration
mode
0
●
P6-08
Time proportion
of S-curve
start segment
0.0%〜（100.0%-P6-09）
30.0%
●
P6-09
0.0%〜（100.0%-P6-08）
30.0%
●
P6-10
Stop mode
0
P6-11
Initial frequency
of stop DC
braking
0.00Hz〜Maximum frequency
0.00Hz
P6-12
Waiting time
of stop DC
braking
0.0s〜100.0s
0.0s
P6-13
Stop DC
braking current
0%〜100% 0%
P6-14
Stop DC
braking time
0.0s〜100.0s 0.0s
P6-15
Brake use ratio
0%〜100% 100%
P6-18
Speed tracking
current
30%~200%
●
P6-21
Demagne-
tization time
0.0~5.0s
●
0: Direct start
1: Speed tracking restart
2: Pre-excitation start
(AC asynchronous machine)
0: Start from stop frequency
1: Start from zero speed
2: Start from maximum
frequency
Rotational
speed
tracking
mode
○
○
●
●
Fun-
ction
Code
Parameter
Name
Setting range
Default
Prope-
rty
Modbus
Address
0: Linear acceleration/
deceleration
1: S-curve acceleration/
deceleration A
2: S curve acceleration and
deceleration B
Time proportion
of S-curve
end segment
0 : Decelerate to stop
1 : Coast to stop
○
○
○
○
○
○
Model
dependent
Model
dependent
User Manual
Chapter 5
User Manual
Chapter 5
P6-23
AVR function
0: No effect
1: Only when deceleration takes
effect 2: Fully effective
2
P6-24
Overexcitation
suppression
current value
0〜9999
P6-25
Overexcitation
gain
0〜9999
300
●
100
●
●
62977
62978
62979
62980
62981
62982
62983
62984
62985
62986
62987
62988
62989
62990
62991
62992
62995
62998
62742
62743
63000
63001
63002
P5-19
Relay 2 delay
time
0.0s〜3600.0s 0.0s
P5-20
Y1 Output
delay time
0.0s〜3600.0s 0.0s
○
○
62740
62741
