Dipped Solid Tantalum Capacitors
Capacity
in uF
1.5V 3.0V 6.0V 10V 15V 20V 25V 35V 50V 100V 200V 300V 400V 500V 600V 1000V
<1.0
1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 3.5 4.9 6.1 7.0 7.8 8.6 11
1.0
1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 3.5 4.9 6.1 7.0 7.8 8.6 11
1.5
1.0 1.0 1.0 1.0 1.0 1.0 1.4 1.0 2.0 4.3 6.1 7.4 8.6 9.6 11 14
2.2
1.0 1.0 1.0 1.0 1.0 1.0 1.8 1.2 2.0 5.2 7.3 9.0 10 12 13 16
3.3
1.0 1.0 1.0 1.0 1.0 1.5 2.2 2.0 3.0 6.4 9.0 11 13 14 16 20
4.7
1.0 1.0 1.0 1.0 1.5 2.0 2.6 2.5 3.5 7.6 11 13 15 17 19 24
6.8
1.0 1.0 1.0 1.5 2.0 2.5 3.0 3.0 6.5 9.1 13 16 18 20 22 29
10
1.6 1.6 1.6 2.0 2.5 3.0 4.1 5.0 7.8 11 16 19 22 25 27 35
15
2.2 2.2 2.2 2.5 3.0 4.0 7.0 5.0 9.6 14 19 23 27 30 33 43
22
2.8 2.8 2.8 3.0 5.0 9.5 10 10 12 16 23 28 33 37 40 52
33
3.4 3.4 3.4 5.0 7.5 15 10 11 14 20 28 35 40 45 49 64
47
4.0 4.0 4.0 10 10 15 15 16 17 24 34 42 48 54 59 76
68
5.0 5.0 5.0 15 15 20 15 17 20 29 41 50 58 65 71 91
100
10 10 10 15 20 20 17 21 25 35 49 61 70 78 86 111
150
15 15 15 20 20 19 21 25 30 43 61 74 86 96 105 136
220
20 20 20 20 20 23 26 31 37 52 73 90 104 116 127 164
330
20 20 20 20 25 28 32 38 45 64 90 110 127 142 156 201
470
24 24 24 24 29 34 38 45 54 76 107 131 152 170 186 240
680
29 29 29 29 35 41 46 54 65 91 129 158 183 204 224 289
1000
35 35 35 35 43 49 55 65 78 111 157 192 221 247 271 350
1500
43 43 43 43 53 61 68 80 96 136 192 235 271 303 332 429
2200
52 52 52 52 64 73 82 97 116 164 232 284 328 367 402 519
3300
64 64 64 64 78 90 101 119 142 201 284 348 402 450 492 636
4700
76 76 76 76 93 107 120 142 170 240 339 416 480 537 588 759
6800
91 91 91 91 112 129 144 171 204 289 408 500 577 645 707 913
10000
111 111 111 111 136 157 175 207 247 350 495 606 700 783 857 1107
15000
136 136 136 136 166 192 214 254 303 429 606 742 847 959 1050 1356
22000
164 164 164 164 201 232 260 307 367 519 734 899 1038 1161 1272 1642
33000
201 201 201 201 245 284 318 376 450 636 899 1101 1272 1422 1557 2011
47000
240 240 240 240 294 339 379 449 537 759 1073 1314 1518 1697 1859 2399
68000
289 289 289 289 353 408 456 540 645 913 1291 1581 1825 2041 2236 2886
100000
350 350 350 350 429 295 553 655 783 1107 1565 1917 2214 2475 2711 3500
150000
429 429 429 429 535 606 678 802 959 1356 1917 2348 2711 3031 3320 4287
200000
495 495 495 495 606 734 783 971 1100 1570 2210 2710 3130 3500 3830 5191
Table 5 - Maximum allowable leakage for solid tantalum electrolytics per EIA standards.
