Sencore ReZolver LC103 User Manual

5
SPECIFICATIONS
IN-CIRCUIT TESTS (Capacitors and Inductors)
Dynamic in-circuit tests to determine whether the
capacitor or inductor is good or bad.
COMPONENT TYPES: Electrolytic, double layer lytic,
tantalum, ceramic, and other capacitors. Yokes,
flybacks, switching transformers, and coils.
RANGE: INDUCTORS – 3.18 uH to 3.18 H
CAPACITORS:
Value: 0.002 uF to 20,000 uF
ESR: 0.02uF to 20,000uF
ACCURACY: Same as Out-of-Circuit tests for known
good inductors and capacitors with no parallel
components.
CAPACITORS (Out-of-circuit)
VALUE
Dynamic test of capacity value is determined by
applying a constant current to the capacitor and
measuring the dV/dt:
10 uA 1.0 pF to 0.2 uF
100 uA 0.2uF to 2 uF
60 mA 2.0 uF to 2,000 uF
416 mA 2,000 uF to 20,000 uF
capacitors from 20,000 uF to 20 F are pulsed with
100 mA
ACCURACY: +/- 1%; +/- l pF; +/- 1 digit for values to
1990 uF; +/- 5%; +/- 0.1% of range, full scale for
values 2000 uF to 19.99 F.
RESOLUTION AND RANGES: 1.0 pF to 19.99 F, fully
autoranged
0.1 pF 1.0 pF to 199.9 pF
1.0 pF 200 pF to 1999 pF
0.00001 uF 0.002 uF to 0.01999uF
0.0001 uF 0.02 uF to 0.1999 uF
0.001 uF 0.2 uF to 1.999 uF
0.01 uF 2.0uF to 19.99 uF
0.1 uF 20.0 uF to 199.9 uF
1.0 uF 200 uF to 1,999 uF
10 uF 2,000 uF to 19,990 uF
100 uF 20,000 uF to 199,900 uF
0.001 F 0.2 F to 1.999 F
0.01 F 2.0 F to 19.99 F
LEAKAGE
ACCURACY: +/- 5%; +/- 1 digit
APPLIED VOLTAGE: Keyboard entry; 1.0 to 1000
volts in 0.1 volt steps; accuracy +0% -5%. Short
circuit current limited to 900 mA, power limited to 9
Watts.
RESOLUTION AND RANGES: 0.0l uA to 20 mA, fully
autoranged
0.01 uA 0.01 uA to 19.99 uA
0.l uA 20.0 uA to 199.9 uA
1.0 uA 200 uA to 1999 uA
0.01 mA 2.00 mA to 19.99 mA
EQUIVALENT SERIES RESISTANCE (ESR)
(U.S Patent #4,795,966)
ACCURACY: +/-5%; +/-l digit
CAPACITOR RANGE: 0.01 uF to 19.99 F
RESOLUTION AND RANGES: 0.1 ohm to 1999 ohms,
fully autoranged for capacitor values greater than or
equal to 1 uF
0.01 ohm 0.1 ohm to 1.99 ohms
0.1ohm 2.0 ohms to 19.9 ohms
1 ohm 20 ohms to 1999 ohms
for capacitor values less than 1 uF
1ohm 1ohm to 1999 ohms
DIELECTRIC ABSORPTION
(U.S. Patent #4,267,503)
ACCURACY: +/- 5% of reading +/- 1 count
RANGE: 1 to 100%
CAPACITOR RANGE: 0.01 uF to 19.99 F
INDUCTORS (Out-of-Circuit)
VALUE (U.S. Patent #4,258,315)
A dynamic test of value determined by measuring the
EMF produced when a changing current is applied to
the coil under test.
CURRENT RATES: automatically selected
19.5 mA/uSec 0.1 uH to 18 uH
1.95 mA/uSec 18 uH to 180 uH
0.195 mA/uSec 180 uH to 1.8 mH
19.5 mA/mSec 1.8 mH to 18 mH
1.95 mA/mSec 18 mH to 180 mH
0.195 mA/mSec 180 mH to 1.8 H
17.5 mA/Sec 1.8 H to 19.99 H
ACCURACY: +/-2%; +/-1 digit +/-0.1 uH
RESOLUTION AND RANGES: 0.10 uH to 20 H, fully
autoranged
0.01 uH 0.l uH to 19.99 uH
0.1uH 20.0 uH to 199.9 uH
1.0 uH 200 uH to 999 uH
0.001 mH 1.000 mH to 1.999 mH
0.01 mH 2.00 mH to 19.99 mH
0.l mH 20.0 mH to 199.9 mH
1 mH 200 mH to 999 mH
0.001 H 1.000 H to 1.999 H
0.01 H 2.00 H to 19.99 H
RINGING TEST (U.S. Patent #3,990,002)
A dynamic test of inductor quality determined by
applying an exciting pulse to the inductor and
counting the number of cycles the inductor rings
before reaching a preset damping point.
INDUCTOR RANGE: 10 uH and larger, non-iron core
ACCURACY: +/- 1 count on readings between 8 and 13
Rings
RESOLUTION: +/- 1 count
EXCITING PULSE: 5 volts peak
