6
SPECIFICATIONS CONTINUED
DISPLAY
COMPONENT TEST RESULTS
TYPE: 2 x 17 Alphanumeric Vacuum Fluorescent
READINGS: Fully autoranged with auto decimal
placement. One or two place holding zeros added as
needed to provide standard value readouts of pF, uF,
uH, or mH.
COMPONENT SETUP
TYPE: 2 x 20 Alphanumeric Vacuum Fluorescent
READINGS: All component types, component value,
tolerance, and voltage rating.
GENERAL
TEMPERATURE: operating range: 32
o
to 104
o
F (0
o
to
40
o
C) range for specified accuracy (after 10 minute
warm-up): 50
o
to 86
o
F (10
o
to 30
o
C)
HUMIDITY: 0-90%, no condensation
MAXIMUM ALTITUDE: 4,000 meters
POWER: 105-130V AC, 60Hz, 30 watts with supplied
PA251 power adapter. Battery operation with
optional BY289 rechargeable battery. 210-230V AC
operation with optional PA252 Power Adapter.
AUTO-OFF: Removes power during battery operation if
unit sits idle longer than 5 minutes.
BATTERY LIFE: 2 hours for typical operation.
SIZE: 6" x 9" x 11.5"
(15.2 cm x 22.9 cm x 29.l cm) HWD
WEIGHT: 6.0 lbs. (2.7 kg) without battery, 7.6 lbs.
(3.4 kg) with battery
GOOD/BAD INDICATION: Functions on all tests.
Requires user input of component type and value, or
input of desired limits.
Specifications subject to change without notice
