40
WEB600 User’s Manual
Password for login string 0 - 16 characters 4x00812
Profile Schedule 42-byte array Any Value 4x00828
Enable/Disable Profile bit TRUE or FALSE 0x00512 10
CONTACTS TYPE VALID RANGE BASE OFFSET
e-mail address string 0 - 64 characters 4x02144 87
Type of communication (voice, e-mail, SMS) uint8 0 - 5 4x02180
Contact Schedule 42-byte array Any Value 4x02206
Enable/Disable Contact bit TRUE or FALSE 0x00768 8
NETWORK TYPE VALID RANGE BASE
DNS Server IP Address uint32 Any Value 3x00000
Gateway IP Address uint32 Any Value 3x00002
IP Address uint32 Any Value 3x00004
Netmask uint32 Any Value 3x00006
HTTP Port uint16 1..65535 3x00008
SMTP Port uint16 1..65535 4x00000
SMTP e-mail server name string 0 - 32 characters 4x00001
Return address for outgoing e-mails string 0 - 32 characters 4x00037
SMTP-AUTH user name string 0 - 32 characters 4x00073
SMTP-AUTH password string 0 - 32 characters 4x00089
SNMP Read-Only/Public String string 0 - 16 characters 4x00256
SNMP Read-Write/Private String string 0 - 16 characters 4x00272
SNMP Manager Server (host or IP) string 0 - 32 characters 4x00288
Time Synchronization Server (host or IP) string 0 - 32 characters 4x00324
Enable/Disable DHCP bit TRUE or FALSE 1x00000
SMTP-AUTH security enable bit TRUE or FALSE 1x00001
Enable/Disable SNMP agent bit TRUE or FALSE 1x00003
SYSTEM TYPE VALID RANGE BASE
Name for unit string 0 - 32 characters 4x00512
Description for the unit string 0 - 32 characters 4x00552
Location for the unit string 0 - 32 characters 4x00592
System time uint32 Any Time >= 2009 4x00632
Call escalation delay (minutes) uint8 Any Value 4x00637
Modbus®/TCP Operating Mode uint8 4x00640
Modbus®/TCP Byte Order (Slave Mode) uint8 4x00641
Modbus®/TCP Port (Slave Mode) uint8 4x00642
Summary Web Page Display Mode uint8 0 or 1 4x00649
Automatic daylight saving time adjustment bit TRUE or FALSE 0x00256
Reset the datalogger bit TRUE 0x00257
Reset the eventlogger bit TRUE 0x00258
System time (string) string Any Time >= 2009 3x00256
