Quick start guide
SidebarMap Area
Control
Bar
Toolbar
Status
Panel
Flight Parameters tab
Camera tab
Mission Waypoints tab
Mission Planning tab
Setup Phase tab
Flight Monitoring tab
sidethe symbol, indicating important status informationincluding theeBee RTK’s
currentaltitude (bothAbove theTake-off Altitude, marked as ATO,and Above
Mean Sea Level, marked as AMSL), battery level, flight time, and status. The
Status Panel can be hidden by clicking on the drone. Moving around the
map is done by clicking and dragging at any place not occupied by a sym-
bol (such as a waypoint or the drone symbol).
• Control Bar: The Control Bar is used to issue various commands to the
