Quick start guide
4.3 The setup phase of a flight
The setup phase of a flight includes the waypoints and actions related to the take-
off and landing of the eBee RTK and includes the following locations:
• Take-off location: The point from which the drone is launched, automati-
cally set to the location calculated from GPS/GLONASS signals by the drone
when it is launched. This location defines the altitude of 0 m/ATO (ATO
stands for above take-off); the altitudes of all other waypoints, when de-
fined in m/ATO, are referenced to the altitude of this location.
• Start waypoint: Thefirst point that the drone flies towards when launched
(once it reaches the take-off transition altitude).
• Home waypoint: The safe point for the drone to circle in case of emer-
gency, as well as its landing position at the end of a flight for both Linear
and Circular landings.
wind
direction
obstacle-
free zones
40m
take-off
transition
altitude reached
10m
60m
Take-off
location
Home
waypoint
Start
waypoint
Approach
sector
50
