Quick start guide
Step 1 Connect your base station to the computer on which you installed eMo-
tion following yourbase station manufacturer’s instructions. The wayyou
connect depends on your base station make and model. eMotion will ac-
cept, for example, serial and USB connections.
Step 2 Click RTK Setup on the eMotion toolbar.
Step 3 In the Local Bases tab, click Add Base.
Step 4 Enter the Base Name.
Step 5 Choose your base station’s manufacturer.
Step 6 From the Connection Type menu, choose the way in which you have con-
nected your base station to your computer.
Step 7 From the next menu (USB or Serial, depending on the Connection Type
you chose), choose your base station.
Step 8 If you are using a serial connection, launch your base station’s configura-
tion tool and use it to check:
• that the serial port configuration (Baud Rate and Stop Bits) shown
in eMotion matches the configuration that your computer is using
to connect to the base station.
• whether your base stationrequireshardwareflow control. If it does,
check the Hardware Flow Control checkbox in eMotion.
Step 9 Click OK to add the base station.
Note: If you have several eBee RTKs connected to eMotion using sev-
eral USB ground modems, they all take correction data from the same
GNSS/RTK base station.
32
