Understanding aerial mapping with the eBee RTK
15˚ 20˚
Landing location
below Home waypoint
60m 10m
50m50m
13.4m
26.8m
3. Circle to
measure wind
4. Fly in calculated direction
5. Glide with controlled
angle and speed
7. Final brake
at 3m
8. Deep stall
to ground
6. Start level
out at 20m
approach sectors
Home
waypoint
calculated upwind
approach direction
calculated downwind
direction
estimated wind
direction
Home
waypoint
1. Aproach Home
waypoint
2. Descend to 75m
above landing
altitude
measure wind
Linear landing procedure, seen from the side
Linear landing procedure, seen from above within
eMotion 2
75m above
landing altitude
