SOHO Power Supply

11

3.4 Power Wiring of the Power Converter

U V W

37PS4N

U V W

L1 L2 L3

P N

L1 L2 L3 E

E

Input Terminal Block

600V 100A 4P

Sunbber B/D

NFB

60A 400V

Fuse

100A 600V

CORE FILTER

OC/2

Film Capacitor

400V 23.3uF

Ootout Reactor

75A 0.56mH

f

1

f

2

f

3

Figure 3.3 Power Wiring of the Power Converter
