Seoho Electric SOHO PS - Parameters

SOHO Power Supply
38
7. Parameters
Colored parameters are with related to the Power Supply. You need to close look about
this.
G1 Basic Control Setup [I]
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P1.0
Rated Power
18.5
0
[kW]
0 ~ 1000
P1.1
Rated Voltage
230
0
[Vrms]
0 ~ 1500
P1.2
Rated Current
72
0
[Arms]
0 ~ 2000
P1.3
Rated Frequency
60
0
[Hz]
0 ~ 3000
P1.4
Number of Poles
4
0
[pole]
0 ~ 24
P1.5
Rated Speed
1800
1800
[rpm]
0 ~ 60000
P1.6
Control Method
0
0
[0] V/F Freq_Ctrl
P1.7
PWM Frequency @Carrier_Freq
6.2
2.5
[kHz]
0.8 ~ 10
P1.9
Supply Voltage
220
0
[Vrms]
0 ~ 1500
G3 RUN_RampCtrl_Config [I]
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P3.0
RUN/STOP Method
0
0
[0] Terminal
P3.1
RampFunc_Input_Src
0
0
[0] Terminal @Digital, Analog
P3.2
STOP Cmd Detection Time
0
0
[s]
0 ~ 10
P3.3
STOP Mode
1
0
[1] Free-RUN STOP
P3.4
STOP Hold-Time
0
0
[s]
0 ~ 300
P3.5
Output OFF Hold-Time
0
1
[s]
0 ~ 30
P3.6
Mixed-Mode STOP Reference
20
20
[%]
0 ~ 500
P3.7
Accel/Decel Ramp Function
0
1
[0] Disabled
P3.8
Accel_Time Range
0
0
[0] 0 ~ 300s
P3.9
Accel_Switching_Ref [1-2]
100
100
[%]
0 ~ 300
P3.10
Accel_Switching_Ref [2-3]
150
150
[%]
0 ~ 300
P3.11
Accel_Switching_Ref [3-4]
200
200
[%]
0 ~ 300
P3.12
Accel_Switching_Ref [4-5]
225
225
[%]
0 ~ 300
P3.16
Acceleration Time I.1 @Region 1
0.2
5
[s]
0.01 ~ 300
P3.17
Acceleration Time I.2 @Region 2
5
5
[s]
0.01 ~ 300
P3.18
Acceleration Time I.3 @Region 3
5
5
[s]
0.01 ~ 300
P3.19
Acceleration Time I.4 @Region 4
5
5
[s]
0.01 ~ 300
P3.20
Acceleration Time I.5 @Region 5
5
5
[s]
0.01 ~ 300
P3.24
Acceleration Time II
10
10
[s]
0 ~ 300
P3.25
Decel_Time Range
0
0
[0] 0 ~ 300s
P3.26
Decel_Switching_Ref [1-2]
100
100
[%]
0 ~ 300
P3.27
Decel_Switching_Ref [2-3]
150
150
[%]
0 ~ 300
