SOHO Power Supply
39
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P3.28
Decel_Switching_Ref [3-4]
200
200
[%]
0 ~ 300
P3.29
Decel_Switching_Ref [4-5]
225
225
[%]
0 ~ 300
P3.33
Deceleration Time I.1 @Region 1
5
5
[s]
0 ~ 300
P3.34
Deceleration Time I.2 @Region 2
5
5
[s]
0 ~ 300
P3.35
Deceleration Time I.3 @Region 3
5
5
[s]
0.01 ~ 300
P3.36
Deceleration Time I.4 @Region 4
5
5
[s]
0.01 ~ 300
P3.37
Deceleration Time I.5 @Region 5
5
5
[s]
0.01 ~ 300
P3.41
Deceleration Time II
10
10
0 ~ 300
P3.42
Counter Deceleration Ramp
Function
0
0
[0] Disabled
P3.43
Counter Deceleration Time
5
5
[s]
0 ~ 300
P3.49
Emergency_STOP Mode
1
0
[1] Free-RUN STOP
P3.50
Emergency_STOP Decel_Time
1
1
0.001 ~ 30
P3.51
Continuous Operation Mode
1
1
[1] Enabled
P3.52
Reverse_DIR Operation
0
1
[0] Disabled
G5 Protection Setup
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P5.0
Current Limit
250
145
[%]
0 ~ 200
P5.1
Current Limit [II]
150
145
[%]
0 ~ 200
P5.7
Max. Continuous Current
@Thermal_Protection
90
95
[%]
0 ~ 250
P5.8
Over-Load Current
@Thermal_Protection
170
135
[%]
0 ~ 250
P5.9
Over-Load Time
@Thermal_Protection
70
60
[s]
0 ~ 300
P5.10
Over Load Fault @Action
2
0
[2] Free_RUN
P5.11
Over-Current Trip
300
220
[%]
0 ~ 300
P5.12
Zero-Sequence Current Trip
15
15
[%]
0 ~ 50
P5.13
Over-Voltage Limiting Function
0
0
[0] Disabled
P5.14
Over-Voltage Limit
670
670
[V]
0 ~ 2200
P5.15
Over-Voltage Trip
780
780
[V]
0 ~ 2200
P5.16
Under-Voltage [UV] Compensation
0
1
[0] Disabled
P5.17
UV Compensation_Voltage
450
450
[V]
0 ~ 2200
P5.18
Under-Voltage Trip
230
360
[V]
0 ~ 2200
P5.19
Open Phase Protection
1
1
[1] Enabled
P5.20
Supply Frequency
60
60
[Hz]
0 ~ 300
P5.21
Built-in Dynamic Brake
1
1
[1] Enabled @RUN
P5.22
DB Switching Frequency
1
1
[kHz]
1 ~ 5
