SOHO Power Supply
24
A
Y
Local Mode
Run
Output Volts>220Vac
①
N
Volts Unbalance < 5%
(Phase to Phase)
N
P21.5 Adjustment
(Leakage Inductance)
Volts Unbalance < 5%
(Under Rated Loading)
N
No Fault?
(F2:Over Current)
Y
N
P5.11 Adjustment
(Over Current Trip)
Full Loading
(Turn-on Aircon.)
Y
10 times < MCCB On/Off N
B
