SOHO Power Supply
30
Figure 6.7 Parameter edition icons
Displayed internal parameters can edit by using with the icons in figure 6.6
Figure 6.8 Communication connection button and waveform viewing area
Communication connection button will toggle as every click. Also it will change if
“Connected” to “Disconnected” or such as opposite case.
Save parameter
Delete parameter
Insert to downward
Insert to upward
