P6.65
AI.5 Max. Voltage
10
10
[V]
1 ~ 10
P6.66
AI.5 Max. Current
20
20
[mA]
2 ~ 20
P6.67
AI.5 Maximum
100
100
[m/m]
0 ~ 500
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P6.68
AI.5 Inversion
0
0
[0] Disabled
P6.69
AI.5 Discreteness
0
0
[0] Disabled
P6.70
AI.5 Dead-Zone
0
0
[0] Disabled
G7 PID Free_Function
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P7.0
Ctrl_Mode
3
0
[3] Free_Function PID
P7.1
Reference_Src
1
2
[1] Fixed Value by
Parameter Setting
P7.2
Fixed Set-Point
100
0
[%]
0 ~ 400
P7.3
Feedback_Src
2
1
[2] Free Function
P7.4
Reference Sign_Change
0
0
[0] Disabled
P7.5
Feedback Sign_Change
0
0
[0] Disabled
P7.6
Control Period @Scan_Time
2
10
[ms]
1 ~ 1000
P7.7
Proportional Gain
120
5
[%]
0 ~ 3000
P7.8
Integration Time @10%error to
100% Output
0.01
30
[s]
0 ~ 300
P7.9
Differentiator Time Constant
0
0
[ms]
0 ~ 30000
P7.10
Feedforward Gain
0
0
[%]
0 ~ 200
P7.11
Zero-Shift Factor
100
100
[%]
5 ~ 100
P7.12
Proportional-Gain 2
5
5
[%]
0 ~ 1000
P7.13
Integration Time 2 @10%error to
100% Output
30
30
[s]
0 ~ 300
P7.14
Differentiator Time Constant 2
0
0
[ms]
0 ~ 30000
P7.15
Feedforward Gain 2
0
0
[%]
0 ~ 200
P7.16
Zero-Shift Factor 2
100
100
[%]
5 ~ 100
P7.17
Output Inversion
0
0
[0] Disabled
P7.18
Integrator Lower_ Limit
-25
0
[%]
-300 ~ 300
P7.19
Integrator Upper_ Limit
15
100
[%]
-300 ~ 300
P7.20
Output Lower_ Limit
-30
0
[%]
-300 ~ 300
P7.21
Output Upper_ Limit
35
100
[%]
-300 ~ 300
P7.22
Output_Scale Func_Src
0
0
[0] Null Data @0
P7.23
Integrator_Ini_Value
0
0
[0] Null Data @0
P7.24
Auto RUN/STOP
0
0
[0] Disabled
P7.25
Auto STOP Delay Time
5
0
[s]
0 ~ 3000
P7.26
Auto START Error Condition
10
10
[%]
0 ~ 50
