P15.17
DC-Brake Current @START
75
75
[%]
0 ~ 150
P15.18
DC-Brake Time @STOP
0
0
[s]
0 ~ 30
P15.19
DC-Brake Blanking Time @STOP
0
0
[s]
0 ~ 30
P15.20
DC-Brake Hold_Current @STOP
75
75
[%]
0 ~ 150
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P15.21
DC-Brake Starting_Current @STOP
90
90
[%]
0 ~ 150
P15.22
Proportional Gain @Current Ctrl
100
100
[%]
0 ~ 1000
P15.23
Integral Gain @Current Ctrl
100
100
[%]
0 ~ 1000
P15.24
Stabilization Time Constant
0.8
0.8
[ms]
0.8 ~ 10
P15.25
Stabilization Gain
10
10
[%]
0 ~ 50
P15.26
Stabilization Limit
0.7
0.7
[%]
0 ~ 2
P15.27
High_Speed Unity_Current_Range
@Frequency
300
300
[%]
100 ~ 500
P15.28
Accel_OC_Protection_Ctrl_Gain
100
100
[%]
0 ~ 3000
G21 Load Constant [I]
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P21.0
Primary (Stator) Resistance 1 (IC)
0
0
[mΩ]
0 ~ 5000
P21.1
Primary (Stator) Resistance (IC)
0
0
[mΩ]
0 ~ 5000
P21.2
Secondary (Rotor) Resistance (IC)
0
0
[mΩ]
0 ~ 5000
P21.3
Primary (Stator) Inductance (IC)
0
0
[mH]
0 ~ 10000
P21.4
Secondary (Rotor) Inductance (IC)
0
0
[mH]
0 ~ 10000
P21.5
Leakage Inductance (IC)
0.61
0
[mH]
0 ~ 1000
P21.6
Inertia Time Constant (IC)
0.6
0.5
[s]
0.01 ~ 5
P21.7
Iron Loss
0
0
[%]
0 ~ 500
P21.8
Viscous Damping
0
0
[%]
-150 ~ 150
G23 Sensor/Hardware Calibration
Par.
NO
Parameter Name
LCD Display
Setting
Default
Unit
Range
P23.0
Effective Blank Time
0
4.075
[us]
0 ~ 10
P23.3
Current Sensing Scale Adjustment
1
1
[p.u.]
1 ~ 1
P23.6
Current Offset @A
-0.902
0
[A]
-30 ~ 30
P23.7
Current Offset @B
1.332
0
[A]
-30 ~ 30
P23.8
Current Offset @C
0.348
0
[A]
-30 ~ 30
P23.9
Current Offset @A2
0
0
[A]
-30 ~ 30
P23.10
Current Offset @B2
0
0
[A]
-30 ~ 30
P23.11
Current Offset @C2
0
0
[A]
-30 ~ 30
