Controls & indicators
Your radio has a number of controls and indicators.
Navi-knob
The Navi-knob is a continuous rotating knob that in its normal mode is used to adjust the volume. The
Navi-knob can also be used to perform various other functions.
To do this… Do this…
Adjust loud speaker volume (or
enable/disable Whisper Mode
[customisable])
Rotate Navi-knob
Move cursor and select characters (in text
entry mode)
Rotate Navi-knob in Text Entry Mode
or Editing Mode
Scroll through available talkgroups
From the Home screen, press
Groups + rotate the Navi-knob
Scroll through available Status Messages
From the Home screen, press
Groups 2 times + rotate the Navi-
knob
Scroll through available User Profiles
From the Home screen, press
Groups 3 times + rotate the Navi-
knob
Navigation Keys
Your mobile radio console has four navigation keys (left/right/up/down).
Key Action
Up/Down
Use to move the scroll bar up and down to see more information.
Scroll a list of options.
To independently adjust the volume of accessories. See Independent
volume control feature on page21
Down Open the top level menu from the Home screen.
Up Repeated presses moves upwards through the options and menu levels until
the top level menu is reached.
Left/Right
Moves between options on the top level menu.
Moves through the text characters for selection when writing.
4 SCC3 colour console
