Doc No. 006-0211-00 Rev AD Page 27 of 62
Figure 21. Surface Choke and Surge Protector Wiring Diagram
Surface Interface
Connection to Scout or
SPS-1500
Red – Gauge Signal
Black – Gauge Ground
Motor Wire Connection
Green – WHG (Wellhead Ground)
Phase A, B, C
