Sercel GRC ESP-Series - Surface Choke

Doc No. 006-0211-00 Rev AD Page 26 of 62
Surface Choke and Surge Protector Panel Assembly
#90B2175
Figure 20. Combined Surge Protector and Surface Choke Panel
Surge Protector
Assembly
Surface Choke Interface to
motor power cable
3 Phase Fuse Assembly
