Doc No. 006-0211-00 Rev AK Page 33 of 33
Note: During normal start-up and synchronization with the sensor you will see “Analyze
1” through “Analyze 16”. You may see messages of “High Amp”, “Low Amp”, “DC to
DC Bad”, as well as other normal messages that are all part of acquiring the tool.
During the Analyzing steps, you will see “SPS Power Off” “Err: Analyzing” two times
and then additional sync phase packets. After the SPS-1500 analyzes the line current
from the sensor, it will check for Enhanced Communication capability and begin to
receive header data from the tool. This is all part of normal operation of the SPS-1500.
received after 5 minutes, proceed to the troubleshooting section of this manual.
