Section 2 Installation Instructions
Part Number 020005256 5/15 2-5
Pre-installation Checklist
When installing any system, first make sure the major components are available. Generally the major components
necessary for an installation are;
Post Mix System
B-I-B System also
Double Check
Also consider the location of the following
Unit Inspection
This section covers unpacking, inspecting, selecting location,
installing the unit, and preparing for operation. The Servend
Drop-In is shipped in a heavy duty corrugated carton
with a wooden pallet. Inspect the Drop-In for freight
damage. If any damage is noticed, stop immediately and
contact your delivering freight company. You must file a
freight claim for your equipment. Failure to do so can
void any claims. Servend is not responsible for any
freight damage, thoroughly inspect the unit upon
delivery. Request a written inspection report from a
claims inspector to document any necessary claim.
1. After the unit has been unpacked, remove the keys.
The key will be needed to perform brixing of valves.
Hold onto the keys until such time to forward them to
the respective owner/operator. Remove tape (which
secures grid in place in drain pan) from grid and
other packing material.
2. Make sure all items are present and in good
condition. Loose shipped items in the carton include
the drain kit parts and the instructions.
3. Inspect unit for any external damages.
If you have an internal carbonated unit the unit is pre-
plumbed at the factory. The inlets for CO
2 and water are
located behind the splash panel. There are two inlets for
water and one inlet for CO
2. If you have questions refer
to the plumbing diagram on your equipment.
CO
2
regulator set
Beverage dispenser
Beverage tubing
CO
2
tank
Carbonator
Stepless (Oetiker) clamps
Chain for CO
2
tank
Carb/Non-Carb Settings
B-I-B connectors
B-I-B regulator set
B-I-B rack
B-I-B syrup boxes
Check Beverage Flavor Line-up
Do you have enough space to install the
dispenser?
Is the countertop level?
Can the countertop support the weight of the
dispenser plus the weight of the stored ice?
Water line
Drain
Power outlet
Heating and air conditioning ducts
